Sleek Design, Ultimate Comfort

  • Save energy | With SEER up to 9.0 and SCOP up to 6.0 (warm zone) see reduced electricity bills
  • Flexible Installation | Install your air conditioner even in spaces with limited height, as the installation can be done just 5cm from the ceiling
  • Uninterrupted Comfort | Enjoy even cooling or heating distribution with the 3D Air Flow function, which allows for horizontal and vertical movement of the louvers
  • Cleaner Air | Breathe cleaner air free from dust, allergens and germs with the 3-stage filtration system (Cold Catalyst, Active Carbon, Silver Ion)
  • Easy Maintenance | Clean and change the filters easily from the top of the unit
  • Lock the temperature limit and receive filter change reminders with the Comfort Hotel Manager
  • WiFi activated

  • attribute-image
  • BTU/h
  • 9.000 / 12.000

    18.000 / 24.000

  • attribute-image
  • Energy Class (Cooling/heating | warmer zone)
  • A+++ | A+++

  • attribute-image
  • SEER | SCOP
  • SEER up to 9.0

    SCOP up to 6.0

  • attribute-image
  • Wi Fi
  • Activated

attribute-image
Wi-Fi Activated

You can remotely control one or more Carrier air conditioners and dehumidifiers with a user-friendly mobile app (available for iOS & Android). The Wi-Fi stick is placed within the product packaging and no additional equipment is required to connect the device.

attribute-image
Gold Fin

Unique anti-corrosive golden coating on the heat exchangers can withstand the salty air, rain and other corrosive elements. It also effectively prevents bacteria from breeding and improves heat efficiency.

attribute-image
Turbo Mode

Turbo function will be helpful to cool or heat your room quickly and effectively.

attribute-image
Eurovent certified

Eurovent’s certification ensures that all technical characteristics labeled on a product by its’ manufacturer are true.

attribute-image
Cold Catalyst Filter

Eliminates formaldehyde and other volatile organic compounds (VOCs) as well as harmful gases and odors. The filter’s effectiveness does not deteriorate over time.

attribute-image
Active Carbon Filter

Removes unpleasant odors 10 times more effectively, such as that of a cigarette.

attribute-image
Silver ion Filter

This filter releases negative ions that refresh the air and provide a clean, refreshing atmosphere.

attribute-image
Follow Me Mode

A temperature sensor built in the remote controller will sense its surrounding temperature. The unit can adjust room temperature more accurately to the area you place the remote controller, to give you greater comfort.

attribute-image
Base Pan Heater

Offers anti-freeze protection even in temperatures as low as -15oC.

attribute-image
X-ECO Mode

By activating this mode, the unit can consume up to 60% less energy, comparing to the normal mode. The unit automatically adjusts the fan speed and the compressor’s rotation providing you the same level of comfort but with the minimum energy consumption.

attribute-image
Active Clean Technology

Washes away dust, mold, and grease that may cause odors when attached to the heat exchanger.

attribute-image
Wind Avoid Me

Choose this mode to redirect the air away from the users.

attribute-image
1W in Standby mode

The unit consumes less than 1W in standby mode.

attribute-image
Chiller leakage detection system

In case of cooling fluid leakage, the unit automatically detects the leak and shuts operation down while at the same it alerts you with the corresponding malfunction code on the indoor unit screen.

attribute-image
Automatic Restart

After a potential power failure, the unit will automatically restart, keeping all previous settings.

attribute-image
Sleep Mode

This mode saves energy and improves night time comfort. The set temperature will increase by 1°C per hour in cooling mode or decrease by 1°C per hour in heating mode, for the first 2 hours of operation. Thereafter the unit will retain the new temperature for 5 hours after which it will switch off automatically!

attribute-image
Auto Defrosting

Prevents evaporator from freezing and maintains dehumidifying effect under low temperature ambient.

attribute-image
Note

The manufacturer reserves the right to change the characteristics of the products, the elements and the images, without prior notice.

SYSTEM38QHE/ 42QHE9D8SH38QHE/ 42QHE12D8SH38QHE/ 42QHE18D8SH38QHE/ 42QHE24D8SH
Cooling capacity kW2.64 (1.32~3.81)3.50 (1.32~3.96)5.20 (3.75~6.13)6.85 (2.11~8.21)
Cooling capacity BTU/h9.008 (4.504 - 13.000)11.642 (4.504 - 13.512)17.743 (12.796 - 20.916)23.373 (7.200 - 28.014)
Heating capacity kW3.00 (0.88-4.40)3.85 (0.88~4.54)5.65 (2.58~6.77)7.30 (1.55~8.21)
Heating capacity BTU/h10.236 (3.003 - 15.013)13.137 (3.003 - 15.491)19.279 (8.803 - 23.100)24.909 (5.289 - 28.014)
Temp range cooling °C-15~50-15~50-15~50-15~50
Temp range heating °C-15~24-15~24-15~24-15~24
SEER/ SCOP(warmer) / SCOP(average) W/W9.0/6.0/4.68.5/5.4/4.68.5/5.6/4.48.6/5.4/4.2
Energy labelA+++/A+++/A++A+++/A+++/A++A+++/A+++/A+A+++/A+++/A+
Yearly energy consumption kWh103/595/731144/648/731215/1118/1369279/1439/1667
Refrigerant amount kg0.690.691.11.5
Voltage, Hz220-240V~, 50/60Hz220-240V~, 50/60Hz220-240V~, 50/60Hz220-240V~, 50/60Hz
INDOOR UNIT42QHE09D8SH42QHE12D8SH42QHE18D8SH42QHE24D8SH
Sound pressure level (Min. ~ Max.) dB(A)21~3722~4022~4121~42
Air flow (Min. ~ Max.) m3/h280~530290~560400~685380~1090
Weight kg10.210.212.320.0
Dimensions (W×D×H) mm795x225x295795x225x295965x239x3191140x275X370
OUTDOOR UNIT38QHE09D8SH38QHE12D8SH38QHE18D8SH38QHE24D8SH
Sound pressure level dB(A)50505256,5
Airflow m3/h2200220035003500
Weight kg28.428.438.845.6
Dimensions (W×D×H) mm805x330x554805x330x554890x342x673890x342x673
