42QTD Inverter XPower Cassette three phase (R32)

Certification Image

Ideal solution for any type of suspended ceiling, thanks to its compact design.

  • attribute-image
  • BTU/h
  • 36000, 48000, 60000

  • attribute-image
  • Energy Label Cooling
  • A++
  • attribute-image
  • Energy Label (Heating/warmer)
  • A+++, A++
  • attribute-image
  • Cooling Capacity
  • 10,50 kW, 14,00 kW, 15,40 kW
attribute-image
Fresh air intake

A ventilation motor can be installed in the fresh-air duct, connected to the ventilation connector, and work with the indoor fan to increase the volume of fresh air (optional).

attribute-image
Compact design

With its small size it can fit to all suspended ceiling installations. It is ideal for offices and large spaces.

attribute-image
Sleep Mode

This mode saves energy and improves night time comfort. The set temperature will increase by 1°C per hour in cooling mode or decrease by 1°C per hour in heating mode, for the first 2 hours of operation. Thereafter the unit will retain the new temperature for 5 hours after which it will switch off automatically!

attribute-image
Wired controller

The unit has wired control.

attribute-image
Chiller leakage detection system

In case of cooling fluid leakage, the unit automatically detects the leak and shuts operation down while at the same it alerts you with the corresponding malfunction code on the indoor unit screen.

attribute-image
Auto Defrosting

Prevents evaporator from freezing and maintains dehumidifying effect under low temperature ambient.

attribute-image
Reserved dry contact ports

With the reserved ports, a remote switch can be easily connected for a remote control. The builtin PCB can produce alarm signal which can be connected to an external alarm light or vibration gauge.

attribute-image
3D DC Inverter

The indoor unit is equipped with a DC inverter fan motor. The outdoor unit is also equipped with DC inverter technology compressor and fan motor. With 3 DC inverter motors the unit achieves maximum performance and energy efficiency.

attribute-image
Remote Control Bright Screen

The remote control has a backlit LCD display for easy reading.

attribute-image
My Mode

The unit memorizes the desired mode and temperature so that you can have the desired operation at a touch of a button.

attribute-image
Dehumidification

In this mode priority is given to dehumidifying the air. To achieve dehumidification the unit operates at low fan speeds and low compressor speeds.

attribute-image
3D Air Distribution

The directional air outlet moves automatically to direct air flow to every corner of the room and keep it thoroughly cool.

attribute-image
Reserved air outlet for duct

A reserved outlet on the side of the indoor unit allows the connection of an air duct to provide air conditioning to nearby rooms from a single unit.

attribute-image
Electrical voltage protection (168 to 264V)

The can fully operate within the power range of 168 to 230V, while also being protected from any fluctuations that may occur within this range.

attribute-image
Automatic Restart

After a potential power failure, the unit will automatically restart, keeping all previous settings.

attribute-image
360 Air Flow

Cassette sizes from 24.000 to 60.000 BTU can distribute airflow evenly to all directions, without “blind-spots”, achieving equal temperature across the room.

attribute-image
Turbo Mode

Turbo function will be helpful to cool or heat your room quickly and effectively.

attribute-image
Note

The manufacturer reserves the right to change the characteristics of the products, the elements and the images, without prior notice.

42QTD012D8S-*-142QTD048R8S42QTD018D8S-1-1
Energy Label CoolingA++A++A++
Energy Label (Heating/warmer)A++A++A+++
Cooling Capacity10,50 kW14,00 kW15,40 kW
Energy Label (Heating/average)A+A+A+
Heating Capacity10,80 kW15,60 kW18,00 kW
SEER6,16,16,1
SCOP (warmer)4,94,65,1
SCOP (average)4,04,04,0
Operating Range °C (Cooling)-15 ~ 50°C-15 ~ 50°C-15 ~ 50°C
Operating Range °C (Heating)-15 ~ 24 °C-15 ~ 24 °C-15 ~ 24 °C
Sound pressure level (high/very low) (dB(A))51/4652/4853/48
Dimensions (WxDxH)Panel 950x950x55Panel 950x950x55Panel 950x950x55
RefrigerantR32R32R32

Download our documents

File imageBrochure
File imageOwners Manual
File imageControl Manual
File imageInstallation Manual
