Minimal αισθητική, maximum απόδοση
The new AMBI air conditioning unit is a true energy-saving mastermind.
- ECO PLUS inverter technology ensures new flash cooling / flash heating | Cools down to 6.3℃ &Warms up to 9.4℃ in 10mins
- BE+ Ion Cloud Advanced Dual Effect Technology Sterilization releases high energy jet flow plasma to sterilize bacteria & purify the indoor air
- 100% Gear plus operation function, can be configured to 5 stage power input levels thereby achieving energy savings with autonomous operation
- The indoor unit can be installed just 2.85 cm from the ceiling
- Double blade for powerful and dynamic airflow direction
- WiFi activated
- BTU/h
9.000 / 12.000
18.000 / 240.000
- Energy Class (Cooling/heating | warmer zone)
A+++ | A++
- SEER | SCOP
SEER up to 8.5
SCOP up to 5.5
- Wi Fi
Activated
BE+ Ion Cloud Advanced Dual Effect
BE+ Ion Cloud Advanced Dual Effect
Technology Sterilization releases high
energy jet flow plasma to sterilize
bacteria & purify the indoor air
Τεχνολογία inverter
Inverter technology for instant cooling/heating | Cools by 6.3°C and heats by 9.4°C within 10 minutes.
Gear +
100% Gear plus operation function,
can be configured to 5 stage power
input levels thereby achieving energy
savings with autonomous operation
ECO
ECO PLUS inverter technology
ensures new flash cooling / flash
heating | Cools down to 6.3°C
&Warms up to 9.4°C in 10mins
ECO technology sustains cooling
output and provides true savings and
comfort.
Flexible Installation
Save space, even near the ceiling : 3cm.
Wind Avoid Me function
With this function, the flow of conditioned air is directed against the users of the space. So you enjoy the desired temperature, without directly feeling the air currents.
Sleep Mode
This mode saves energy and improves night time comfort. The set temperature will increase by 1°C per hour in cooling mode or decrease by 1°C per hour in heating mode, for the first 2 hours of operation. Thereafter the unit will retain the new temperature for 5 hours after which it will switch off automatically!
Follow Me Mode
A temperature sensor built in the remote controller will sense its surrounding temperature. The unit can adjust room temperature more accurately to the area you place the remote controller, to give you greater comfort.
Silent mode
Silent design achieved with larger
crossflow fan, and new motor curved
design, can go as low as 15~17dB.
Extreme performance
Extreme performance for cooling and heating from-25°C to 50°C
Turbo mode
It achieves the desired temperature quickly and efficiently.
Active Clean cleaning system
Removes dust, mold and grease that can cause odors when they adhere to the heat exchanger.
Dehumidification function
By activating this function, the device automatically selects the desired humidity levels, between 45% – 55%, always depending on the room temperature. It ensures the continuous maintenance of the appropriate percentage of humidity, offering excellent air quality with maximum energy savings.
Auto Restart
In the event of a power failure, the unit automatically restarts with the previous settings.
Self Diagnosis & Auto Protection
Once abnormal operation or part failure happens, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.
Wi-Fi
Activated
Bluetooth Controller (optional)
Α detachable wallmounted bluethooth remote
5 YEARS WARRANTY
Carrier offers 5 years of warranty for all unit parts.
Note
The manufacturer reserves the right to change the characteristics of the products, the elements and the images, without prior notice.
| ΣΥΣΤΗΜΑ | 38QHG / 42QHG009D8SUP | 38QHG / 42QHG012D8SUP | 38QHG / 42QHG018D8SUP | 38QHG / 42QHG024D8SUP |
|---|---|---|---|---|
| Ψυκτική Απόδοση kW | 2,75 (1,00-3,20) | 3,65 (1,40-4,30) | 5,28 (3,40-5,90) | 7,04 (2,10-8,20) |
| Ψυκτική Απόδοση BTU/h | 9.383 (3.412 - 10.919) | 12.454 (4.777 - 14.672) | 18.016 (11.601 - 20.132) | 24.021 (7.165 - 27.980) |
| Θερμική Απόδοση kW | 2.90 (0.8-3.4) | 3.90 (1.1-4.4) | 5.70 (3.1-6.7) | 7.50 (1.5-8.2) |
| Θερμική Απόδοση BTU/h | 9.895 (2.730 - 11.601) | 13.307 (3.753 - 15.013) | 19.449 (10.578 - 19.790) | 25.591 (5.118 - 27.980) |
| Εύρος λειτουργίας ψύξης °C | -15~50 | -15~50 | -15~50 | -15~50 |
| Εύρος λειτουργίας θέρμανσης °C | -15~24 | -15~24 | -15~24 | -15~24 |
| SEER / SCOP (θερμή ζώνη) / SCOP (μεσαία ζώνη) W/W | 7.4 / 5.3 / 4.1 | 7.0 / 5.5 / 4.2 | 7.0 / 5.1 / 4.0 | 6.5 / 5.1 / 4.0 |
| Ενεργειακή Κλάση | A++ / A+++ / A+ | A++ / A+++ / A+ | A++ / A+++ / A+ | A++ / A+++ / A+ |
| Διαστάσεις Eσωτερικής μονάδας (Π×Β×Υ) mm | 726×210×291 | 835×208×295 | 969×241×320 | 1083×244×336 |
